    • Elektrische Plafondbeugel tot 75 inch tvb-107

    Wolff Mount Full Motion Electric Ceiling Mount | up to 75 inch | 35kg | VESA 600x400 | With App and AB

    (2595)
    Brand:
    Wolff Mount
    Article number:
    TVB-107
    TV dimensions:
    32 inches t/m 75 inches
    VESA sizes:
    200x100 t/m 600x400
    Ordered before 5pm on weekdays, shipped today
    10,000+ satisfied customers went before you
    Professional advice by email and telephone - Mon to Fri
    B2B fast delivery through our own stock | On account also possible
    €399,00 - €399,00
    €399,00
    €399,00
    €399,00 - €399,00
    €399,00
    (Excl. VAT: €329,75)
    In stock

    Best rated TV Bracket Supplier in the Netherlands & Belgium

    We are proud of the 2514+ customers who have rated us with a 9+. Additionally, 96% recommend us!

    Wolff Mount Full Motion Electric Ceiling Mount | up to 75 inch | 35kg | VESA 600x400 | With App and AB
    Fast delivery

    Ordered before 5:00 PM on weekdays, shipped today

    Secure Payment

    iDEAL, PayPal and pay later via Klarna

    Free shipping on orders over €100

    Not satisfied = money back

    Customer service

    Tel: 088 112 0500

    Specificaties

    Brand support
    Wolff Mount
    Article number
    TVB-107
    Barcode EAN
    8720726078603
    Type of support
    TV Ceiling Mount
    TV dimensions
    32 inches t/m 75 inches View all
    32 inches
    33 inches
    34 inches
    35 inches
    36 inches
    37 inches
    38 inches
    39 inches
    40 inches
    41 inches
    42 inches
    43 inches
    44 inches
    45 inches
    46 inches
    47 inches
    48 inches
    49 inches
    50 inches
    51 inches
    52 inches
    53 inches
    54 inches
    55 inches
    56 inches
    57 inches
    58 inches
    59 inches
    60 inches
    61 inches
    62 inches
    63 inches
    64 inches
    65 inches
    66 inches
    67 inches
    68 inches
    69 inches
    70 inches
    71 inches
    72 inches
    73 inches
    74 inches
    75 inches
    VESA size
    200x100 t/m 600x400 View all
    200x100
    200x200
    300x200
    200x400
    400x200
    300x300
    400x300
    400x400
    600x400
    Maximum load
    35kg
    Tiltable downwards
    75 degrees
    Functions
    Rotatable
    Electrically Foldable
    Number of pivot points
    1
    Electric
    Yes
    Warranty
    2 years
    Color
    Black
    Rotatable
    180 degrees

    Full-motion large fold-out electric ceiling bracket

    This is undoubtedly the showpiece among electric folding ceiling mounts . Here are a few features: up to 75 inches , up to 35 kilos , and both in/out and left/right rotation. The special thing about this electric TV mount is that it can lift very large screens up to 75 inches, with the option of rotating left and right. That makes this ceiling mount TV truly complete. Keep in mind that 35 kilos is the maximum weight the ceiling mount can fold and unfold. A 75-inch OLED TV quickly exceeds this weight, so we advise against it due to gravity and the load on the motor.

    Use and operation

    Using and operating this WOLFF MOUNT TVB-107 electric ceiling mount is easy with the Tuya app or the included remote control. You can easily save and activate memory settings. Rotate your TV up to 180 degrees for a comfortable viewing angle or fold it away to save space. A balanced mechanism prevents ceiling vibrations when the TV is moving. The anti-collision system prevents collisions and stops the TV from rotating if it encounters obstacles.

    Product specification:

    • Suitable for screens from 32 to 75 inches
    • VESA connection 200x100 - 600x400
    • Maximum load of 35 kilos
    • Works on 220v
    • Tilt angle up to 75 degrees
    • Rotatable up to 180 degrees
    • Controls with APP or remote control
    • Silent powerful electric motor
    • Balanced vibration mechanism

    Technical installation description – Electric ceiling bracket

    Application

    The electric ceiling mount is suitable for mounting a flat-screen television up to 75 inches. The mount is electrically tiltable and designed for ceiling mounting.

    Dimensions (mm)

    Top / ceiling plate:

    • Total length: 500 mm
    • Internal dimensions: 406 mm
    • Mounting plate center: 102 mm
    • Right segment: 266 mm
    • Internal right dimension: 202 mm
    • Depth: 430 mm

    TV mounting frame:

    • Horizontal VESA compatibility: 200 – 600 mm
    • Total frame width: 660 mm
    • Vertical VESA compatibility: 81 – 410mm

    Height range:

    • Minimum total height: 140 mm
    • Maximum total height: 735 mm

    Tilt and swivel range

    • TV tilt range: 0° to -75°
    • Fine adjustment: +2° / -2°
    • Rotation of upper part: ±90°


    Assembly instructions:

    Step 1 – Check the substrate

    • Check whether the ceiling is structurally suitable (concrete or load-bearing beam).
    • Use suitable mounting material tailored to the ceiling type.
    • The minimum load-bearing capacity of the ceiling structure must significantly exceed the total weight of the bracket and TV.

    Step 2 – Fixing the ceiling plate

    • Position the ceiling plate (500 mm length).
    • Mark the drill holes.
    • Drill the holes according to the type of mounting anchor.
    • Install the ceiling panel level and fully tighten all fasteners.

    Step 3 – Assembling the scissor mechanism

    • Check that the scissor/lift mechanism can move freely.
    • If applicable, connect the electrical power supply according to specifications.
    • Test the movement without the television mounted.

    Step 4 – Mounting TV brackets

    • Attach the vertical TV rails to the back of the TV according to the correct VESA pattern (200–600 mm horizontal, 81–410 mm vertical).
    • Use the supplied spacers if necessary.
    • Ensure bolt length is correct to avoid damage to the device.

    Step 5 – Hanging the television

    • Hang the television in the frame.
    • Lock the mounting system.
    • Check that the TV is correctly centered and hanging stably.

    Step 6 – Adjustment

    • Adjust the tilt angle (0° to -75°).
    • If necessary, make fine adjustment (+2° / -2°) for perfect alignment.
    • Check the rotation range (±90°).

    Safety instructions

    • Installation must only be carried out by a qualified person.
    • Only make the electrical connection when the power is de-energised.
    • Check all mounting points periodically.
    • Never exceed the maximum load capacity of the bracket.

    Watch our product video
